PowerVision PDF User Manuals

Hi! On this page you can download PDF user manual for such PowerVision drones as: PowerRay, PowerEgg, PowerEye, PowerBee.

PowerVision logo
PowerVision logo

Title

File Size

Download Link

PowerVision PowerEgg Users Manual.pdf

2.3Mb

Download

PowerVision PowerEye Users Manual.pdf

3.7Mb

Download

Drone PowerEgg of PowerVision

Review

At the beginning of this year, PowerVision introduced a proto-drone called PowerEgg. This name was given to the drone due to its ovoid shape. It can be said for sure that the drone made in the shape of an egg immediately attracted the attention of many UAV enthusiasts, and as a result it became known not long ago that anyone who is already ready can now preorder the drones on the official site of PowerVision.

PowerEgg
PowerEgg

Recall that in addition to a powerful camera suspended on a three-axle suspension and shooting video as a 4K at 60fps, a drone can fly obstacles at a height of up to 4 meters, broadcast a video stream to any tablet or smartphone up to 5 km., Develop a flight speed of up to 47 Km / h. (13m / s = 46.8km / h.), With a total flight time of up to 23 minutes. Also, 3 programmed flight modes will be available. Point of Interest / Flight by points / Follow me. The weight of the drone is only 2 kg.



The control will be performed both by the classical control panel and by the Maestro remote control, thanks to which it is possible to control the drones with gestures of just one hand. Quality of execution at a very high level as well as its cost, at the current moment the price of PowerEgg is €1,499.00. In the kit with the drone will come, Believe the stand (the base on which stands the drone), the charger, the battery for PowerEgg (14.8v 6400 mAh 94.72wh LiPo), the transmitter in the classic version, the holder for the tablet / smartphone, the Maestro remote control, the backpack for Transportation of the drone.

Specification

Optical positioning

Diposon heights: 0.2 - 4 m

Speed Diposon: ≤ 4 m / s (2 m above ground)

Wednesday: Surface with a clear pattern and adequate lighting (Lux> 15)

Drone

Max. Practical ceiling above sea level: 4km.

Dimensions: 272 × 176 mm (closed) / 272 × 476 mm (in the flight)

Power: 265 - 450W

Weight: 2.1kg.

Maximum speed: 46.8 km / h (in the Professional mode)

The diagonal size is 448mm.

Max. Speed of descent: 7.2 km / h.

Max. Lifting speed: 18 km / h.

Temperatures. Wednesday: 0 ° - 40 ° C

The size of the main screws: 26.67 cm.

Operating frequency: 2.4GHz

Max. Flight time: 23 min.

GPS mode: GPS and BeiDou

Camera

The maximum size of an image is 4.254 × 3.264; 2.840 × 2.160; 2.560 × 1.920

ISO range: 100 - 3.200 (video); 100 - 1.600 (photo)

Temperatures. Wednesday: -10 ° to 40 ° C

Sensor: 1 / 2.3 "CMOS

Maximum video transfer rate: 60Mbps

Compatible with SD cards: Micro-SD; Max.capacity: 64GB or UHS-1 class 10

Compatible formats: FAT32 / exFAT, JPEG, DNG, MP4, MOV (MPEG-4 AVC / H.264)

Lens: FOV 95 ° 22 mm (35 mm format equivalent) f / 2.8G

Shutter speed: 8 sec. Up to 1 / 8,000 sec.

Video recording modes: UHD: 3840 × 2160 at 30fps; FHD: 1920 × 1080 30/60 / 120fps; HD: 1280 × 720 60/120 / 240fps

Photo modes: Single / continuous shooting: 3/5/10 frames; Automatic (AEB): 3/5/7 bracketed frames; Self-timer: 5/10 / 30s; At 0.3EV offset; Slow motion: 1/30, 1, 2, 5, 10, 20, 30, 60s.

Suspension

Controlled tilt range: 0 - 90 °

Stabilization: 3-axis

Controlled noise range: -120 ° to + 170 °

Control accuracy: 0.05 °

Standard control panel

Battery: 1S 2800mAh LiPo

Charge time: 3 hours

Temperatures. Wednesday: 0 ° - 40 ° C

Working time: 20 hours

Operating voltage: 120mA / 3.7 V

PowerEgg Maestro

Battery: 1S 1400mAh LiPo

Charge time: 2 hours

Temperatures. Wednesday: 0 ° - 40 ° C

Working time: 10 hours

Operating voltage: 120mA / 3.7V

PowerEgg Smart Battery

Capacity: 6400mAh

Charge current: 2С

Net weight: 580gr.

Temperatures. Wednesday: -10 ° to 40 ° C

Voltage: 14.8V

Battery Type: LiPo

Charger

Output Port 1: 16.8V ± 0.1V; <5A

Output Port 2: 5V ± 0.1V; <6A

Temperatures. Wednesday: -10 ° to 45 ° C

Input voltage: AC 100 - 240V

Chat: 50 / 60Hz

Rated Power: 114W

Main station

Delay: 300ms

Battery: 1S 2300mAh LiPo

Temperatures. Wednesday: 0 ° - 45 ° C

Operating voltage: 800mA / 3.7V

Max. Range of video transmission: 5km.

Transmitter power: 20dbm CE, 28 dbm FCC

Operating frequency: Drone - transmitter: 2.400 - 2.483GHz; Transmitter - other devices: 5.725GHz - 5.875GHz

Charging time: 3 hours

Working time: 1.5 hours

Conclusion

Pros:

  • quality
  • design
  • camera
  • Compactness
  • Autonomy
  • Broadcast video up to 5km (on any gadget)
  • Maestro Remote
  • Backpack for transportation

Cons:

  • price
  • No spare screws
  • the weight

A modern, high-tech, fully autonomous drone has won recognition of the public due to its unusual shape, will become an indispensable assistant in a photo / video session for everyone without reference to the experience of owning UAVs. The only significant disadvantage of this drone is its price.
